FEATURES: The classic saw design improved and updated for the modern user New 1400 watt motor for powerful cutting in all materials XPS Shadow line cut indicator provides fast accurate alignment of the blade while illuminating the work piece for increased productivity no adjustment required Improved Dust extraction efficiency The base and fence have been machined to meet the accuracy requirements of the most demanding applications New head lock function allows the head to be fixed, restricting the traverse function for trim applications and ease of transportation Integrated positive mitre stops at 15 degree, 22.5 degree, 30 degree, 45 degree, quick release mitre mechanism up to 50 degree Fixed left and right hand fences with measuring scale for improved material support and management Compact internal rail design for huge cutting capacity in a highly transportable format Carry side handles for easy transportation SPECIFICATIONS: Blade Diameter: 216 mm Blade Bore: 30 mm Bevel Capacity: 48 degree Mitre Capacity (Right/Left): 48 degree Maximum Depth of Cut (Saws): 70 mm Hand/Arm Vibration (Cutting Wood): 2.1 m/s² Maximum Cutting Capacity (45/45 degree): 190 x 48 mm Maximum Cutting Capacity (90/45 degree): 173 x 62 mm Maximum Cutting Capacity (90/45 degree): 265 x 48 mm Maximum Cutting Capacity (90/90 degree): 250 x 62 mm Maximum Cutting Capacity (90/90 degree): 250 x 60 mm Maximum Cutting Capacity (45/90 degree): 177 x 62 mm Maximum Cutting Capacity (45/90 degree): 177 x 60 mm No-Load Speed: 0 – 4500 rpm Power Input: 1400 watt Power Output: 1100 watt Uncertainty K 1 (Vibration): 1.5 m/s² Sound Power Level: 104 dB(A) Sound Power Uncertainty: 3.9 dB(A) Sound Pressure Level: 93 dB(A) Sound Pressure Uncertainty: 3 dB(A) Length: 490 mm Height: 590 mm Width: 550 mm Weight: 12 kg INCLUDES: TCT tooth saw blade Blade spanner Material Clamp
