STANDARD INDUSTRIAL 250 Ton x 16-20 ft Hydraulic CNC Press Brakes AB250-16

Description Standard Industrial is 100% Owned, Operated and Manufactured In The U.S.A. Full-Tonnage Throughout Stroke Typical 30 Year Lifetime, Plus a Lifetime of Parts and Service Availability Solid, Non-Moveable Lower Beam Substantially More Rigid Than “Bed Level” press Brakes ,- .001″ Ram Repeatability Off-center loading Capability The Most Heavy Duty Press Brake Built In The U.S.A. Extremely Heavy-duty lower beams allowing the least amount of deflection. Less Deflection = Longer Tool Life = More profitability Precision mechanical in-line depth stop as back-up for any CNC control Single Cylinder Hydra-Mechanical Drive System New Manifold Based Hydraulic System *Contact Sheet Metal Machines if overall heights are critical. *Bed heights can be lowered with full machine pits *Contact Sheet Metal Machines for specifications on other size brakes FOR MORE FEATURES: CLICK HERE SPECIFICATIONS: MODEL: AB250-16 Tonnage Forming/Punching: 250/175 Bed Ram Length: 16′ Distance between Housings: 14′-5″ Open Height: 16″ Stroke Length: 8″ Closed Height: 8″ Below Grade: No Approach Press Return: 20 h.p. 102-16-132 Throat Depth: 10″ Bed Width: 10″ Weight (prox. lbs.): 56,000 MODEL: AB250-20 Tonnage Forming/Punching: 250/175 Bed Ram Length: 20′ Distance between Housings: 18′-5″ Open Height: 16″ Stroke Length: 8″ Closed Height: 8″ Below Grade: Yes Approach Press Return: 20 h.p. 102-16-132 Throat Depth: 10″ Bed Width: 10″ Weight (prox. lbs.): 88,000 *Contact Sheet Metal Machines if overall heights are critical. *Bed heights can be lowered with full machine pits *Contact Sheet Metal Machines for specifications on other size brakes Specifications are subject to change without notice. NOTE: Data is provided by the manufacturer. WARRANTY: 5 YEAR – STANDARD Parts & Limited Labor OPTIONAL ITEMS: Optional AUTOMEC CNC Control Easy to read mechanical ram level indicator and simple, precise ram level adjustment Counterbalance valve for punching and blanking to provide minimum shock Mechanical in-line depth stop to set the top limit, the speed change and a micrometer adjustable lower limit for the most precision bends All parts are readily available from your local suppliers-off the shelf parts for a lifetime All parts are listed in the press brake manual with detailed drawings and the original manufacturers part number so you can always find parts for your press brake Hydraulic reservoir with oil filter—Oil is not included Electric disconnect switch with magnetic starter—Simply run your power to the box Full tonnage the entire length of the bed and ram Full tonnage throughout the stroke—Full tonnage is developed anywhere in slow speed Both ends of ram tapped to accept your four way die lifters Incredibly simple and versatile hydraulic and electric controls Spring loaded die clamps for easy, quick die change Ram readily accepts standard or safety tang dies—Can optionally be fitted to accept European tooling Positive single cylinder hydra-mechanical drive system Electric anti-whip control for your operators safety Overload protection to avoid damaging the press brake Shock-less, quite operation Fully adjustable stroke, open height and speed change Extremely heavy duty, rigid, all steel unitized frame Lube fittings at all bearing points All liquid tight electrical components (2) 24″ support/gauging arms Hydraulic pressure tonnage control with gauge Die groove in bed with set screws in front and rear of brake bed Portable 2 hand control station with normal-inch (jog) modes, E-stop and palm buttons All Standard Industrial press brakes are stringently designed to meet O.S.H.A and ANSI B11.3 standards as well come complete with J.I.C. type and U.L. listed electrical components
