- Description Weighing in at just over 1750 pounds, this motorized H-frame press is built to last. Its welded .375” plate steel structure can handle all the hydraulic system’s force without flexing. 66 tons of hydraulic force. 40.94” working width. 9.85” cylinder stroke. Runs on 220 volt 3-phase power. Robust 5.3 hp motor runs on has 2 working speeds: rapid descent and slow approach. Hand pump gives you the option for even finer control. Cylinder moves left or right within the framework to deliver pressure on off-center parts. 7.08”-diameter cylinder automatically returns to the top once the job is done. 53.34” table fabricated to exacting tolerances. Table features 2 support pins that are 2” in diameter, letting you lock the table in at the correct working height. Lifting chains help with the placement of the table and save you muscle strain. Includes pressure regulator and ram cap. Baileigh covers this hydraulic shop press with a 1-year parts warranty as well as lifetime technical support by phone. SPECIFICATIONS: Return Speed: .393″ / sec. Maximum Pressure: 3814 psi Motor: 5.3 hp Piston Head Diameter: 3.94″ Pump Speed: .871 / 3.619 / gal/min. Oil Capacity: 7.92 gal Working Speed: .086″ / sec. Working Width: 29.52″ System Oil Capacity:2.11 gal Lowering Speed: .362″ / sec. Maximum Capacity: 66 tons Cylinder Stroke: 9.85″ Cylinder Movable: Yes Cylinder Diameter: 8.26″ RPM: 3000 Power: 220 Volt, Three Phase Shipping Weight: 1,764 lbs. Shipping Dimensions: 60″ x 40″ x 81″ Specifications are subject to change without notice. NOTE: Data is provided by the manufacturer. WARRANTY: 1 YEAR – Parts
