TIRWARE Advance Tyre Pressure Monitoring System for Smartphones

Playlist 7 Videos Overview of What it is and Whats in Kit 4:06 Installing Vhedia TPMS Aware App on IPhone 3:28 TPMS Aware app all setting Iphone 5:26 How Tire Pressure Alerts Work 1:02 How to Install Vhedia External TPMS Sensors – Quick & Easy Guide! 0:40 How to Replace the Battery in Your Vhedia External TPMS Sensor – Step-by-Step Guide 1:19 How Sleep Mode Works on TPMS Sensors 1:22 Tirware TPMS Sensors by VhediaMonitor up to 10 tyres in real-time via our Tirware App perfect for vehicles and caravans. Quick to install with long-lasting internal or replaceable external sensors. Includes USB receiver; add a repeater for trailers or extended range. Custom alerts keep you safe with instant tyre pressure and temperature warnings. TPMS App Download Via PlayStore/AppStore Click here to Download Click here to Download Real-Time Tyre Pressure Monitoring Live display of each tyre’s pressure and temperatureIntuitive vehicle layout ensures quick interpretationImmediate visual alerts for anomalies (e.g. low pressure, high temperature) Vehicle & Trailer Monitoring Monitor up to 10 tyres across both vehicle and caravan/trailer setups Ideal for travellers, caravanners, and long-haul driversEasy Caravan or Trailer Disconnection just press the caravan icon Customizable Alerts & Visual Options Set individual thresholds for high/low pressure and temperatureToggle visual alerts, sound alarms, and spare tyre visibilitySwitch between On-Road and Off-Road monitoring modesQuickly switch between on-road and off-road settings when adjusting tire pressure for highway or off-road driving. Easy Sensor Pairing Quick setup with unique sensor IDsManual or automatic pairing optionsVisual confirmation of sensor mapping to tyre positions RECEIVER/REPEATER SPECS ItemSpecification Input VoltageDC 4.5V to 5V from USB Port Working Current≤10mA HF Receive Frequency433.92MHz ± 50KHz HF Receive Sensitivity<-95dBm Working Temperature Range-40°C to 125°C Data Transmission ModeUSB INTERNAL SENSOR SPECS ItemSpecification Battery ModelCR2050 (350mAh) RF Frequency433.92 MHz ± 38 KHz Standby Current< 0.7 μA Emission Current< 8 mA HF Emission Power< 8 dBm (50Ω) HF Modulation ModeFSK LF Receive Frequency125 KHz ± 5 KHz LF Modulation ModeASK Pressure Measurement Range0–800 kPa (0–116 psi) Pressure Accuracy±10 kPa / ±2.9 psi (0°C–70°C)±48 kPa / ±6.96 psi (–40°C–125°C) Temperature Range–40°C to 125°C Temperature Resolution1°C Temperature Accuracy±3°C (0°C–70°C) Working Temperature–40°C to 125°C Storage Temperature–40°C to 125°C Protection GradeIP67 Battery LifespanOver 5 years EXTERNAL SENSOR SPECS ItemSpecification Battery ModelCR1632 (140mAh) RF Frequency433.92 MHz ± 38 KHz Standby Current< 0.7 μA Emission Current< 8 mA HF Emission Power< 8 dBm (50Ω) HF Modulation ModeFSK LF Receive Frequency125 KHz ± 5 KHz LF Modulation ModeASK Pressure Measurement Range0–800 kPa (0–116 psi) Pressure Accuracy±10 kPa / ±1.45 psi (20°C–50°C)±48 kPa / ±6.96 psi (–40°C–125°C) Temperature Range–40°C to 125°C Temperature Resolution1°C Temperature Accuracy±4°C (0°C–70°C) Working Temperature–20°C to 85°C Storage Temperature–20°C to 85°C Protection GradeIP67 Battery LifespanOver 1 year (replaceable) QUICK INSTALLATION AND SETUP External Sensors Plug the USB receiver into a power source (e.g. cig plug). Install the TPMS Aware app from the Apple AppStore or Google PlayStore. Open the TPMS Aware app on your smartphone. Screw the sensors onto the tyre valves and confirm pressure readings in the app. Take the car for a short drive and verify the readings update. Then refer to the video/manual for settings. If using a repeater, mount it near the caravan hitch with 12V power. Use the included 9V battery clip for quick testing before permanent installation. Internal Sensors Plug the USB receiver into a power source (e.g. cig plug). Install the TPMS Aware app from the Apple AppStore or Google PlayStore. Open the TPMS Aware app on your phone. Install the internal sensors on the inner rim of each tyre, ensuring tight, aligned placement to prevent air leakage. Take the car for a short drive and verify the readings update. Then refer to the video/manual for settings. If using a repeater, mount it near the caravan hitch with 12V power. Use the included 9V battery clip for quick testing before permanent installation. FAQ'S FREQUENTLY ASKED QUESTIONS 1. What is the Internal TPMS Sensor? The Internal TPMS (Tyre Pressure Monitoring System) Sensor is designed to monitor tyre pressures and temperatures in real-time. It works with the Tirware TPMS system to track up to 10 tyres across vehicles and caravans for improved safety and performance. 2. How does it differ from external sensors? Internal Sensors: Installed inside the tyre on the inner rim. They are not visible externally, and each includes a built-in battery with a 3–5 year lifespan. External Sensors: Screwed onto tyre valves, easy to install and remove, and typically come with replaceable batteries. 3. What components are needed for a complete setup? A complete TPMS system includes: Internal or external sensors A USB receiver to collect the sensor data A signal repeater (recommended if using with caravans or trailers) 4. How do I install the internal sensors? 1. Plug in the USB receiver to your preferred device. 2. Install the TIRWARE app. 3. Mount the internal sensors to the inner rim of each tyre (this must be done when the tyre is removed from the wheel). 4. Drive the vehicle to allow the sensors to transmit data. 5. If using a repeater, install it near the trailer or caravan connection and wire it to a 12V power supply. 5. Can I mix internal and external sensors? Yes, the system supports a mix of internal and external sensors. This is especially useful for setups involving towing vehicles and trailers or caravans. 6. How long do the internal sensor batteries last? Each sensor has a built-in battery that lasts approximately 3–5 years. The batteries are not replaceable, so new sensors will be required after battery depletion. 7. What is the function of the repeater? The repeater strengthens the sensor signal, ensuring reliable data transmission over longer distances — ideal for caravans, trailers, or vehicles with extended wheelbases. 8. How can I monitor the tyre data? Tyre pressure and temperature data can be monitored in real-time through the TIRWARE app. The system also allows you to set custom alerts for under- or over-pressure and high-temperature readings.
