Description Description LR1 MS76 76cm / 30″ The LR1 MS76 Side discharge Mini-Rider has fantastic features like the space-saving design, great agility and outstanding cutting performance. Thanks to their space-saving design, these models are almost as compact as a conventional walk behind mower in terms of garage space. This compact Mini-Rider with electric start is equipped with a powerful Cub Cadet engine and a 6 speed transmatic transmission allowing for shift-on-the-go speed control. ENGINE LR1 MS76 Engine Cub Cadet OHV Engine displacement (cm3) 382 Rated power (kW/min-1) 7.9 / 2,900 Cylinders Single Fuel tank capacity(l) 4.9 Lubrication Fully pressurised automotive-style oil pump with spin-on oil filter DRIVE SYSTEM Transmission Transmatic Air speed (max) 6 (f/r), shift-on-the-go Control Foot pedal control with lever for manual pre-selection CUTTING SYSTEM Mowing area (m2/h) 3,000 Cutting width 76cm (30”) Cutting height 38–95 mm Cutting options 3-in-1 option Number of blades 1 Deck Engagement Manual lever control Deck height positions 5 positions Wash nozzle / mulching plug Standard/Optional DISCHARGE SYSTEM Grass bag capacity (l) / accessory no. Optional 115 litres/(19A30014OEM) Bag lever / hardtop – / – Bag full indicator / Grass Deflector – / Standard Grass bag capacity (l) Optional 115 litres FRAME Front axle Steel Front bumper – Turning radius (cm) 46cm /18 Wheels (front/rear) (Zoll) 13 x 5 / 16 x 6.5 Wheel bearings Sleeve bearings Frame Easy entry frame ELECTRIC Battery 12V wet battery 115 CCA Headlights – COMFORT Seat type Comfort Seat Seat adjustment Tool-less Steering wheel Standard Mow in reverse Standard Battery charger (196-967-678) DIMENSIONS Noise values (dB) 88 / 98 / 100 Vibration value body (K-factor) (m/s2) 1.0 / 0.5 Vibration value hand-arm (K-factor) (m/s2) 5.0 / 1.5 Dimensions (L / W / H) (cm) 157 / 85 / 112 Weight net (kg) 126
