Description A free standing general fabrication wrap brake. The AIR FOLDER is ideal for forming and bending panels and other flanged metal parts. Pneumatic operated, foot pedal control. Rugged welded steel construction. Maintenance-free bearing and guides. Pneumatic drive folding beam. Safety interlock controls. Dial-adjustable bend angle 0-90°. Automatic TDC/F notch locator. Pneumatic drive clamping beam with automatic return SPECIFICATIONS: Capacity: 14 – 16 gauge (1.6 – 2.0 mm) Depth of Pocket: 1/2” (12.7 mm) – uses 1-3/8” (34.9 mm) of material Maximum Bend Length: 60″ (1525 mm) Maximum Galvanized Steel Thickness: 1/16” (1.6 mm) Minimum Wrap Duct Size: 8.7” x 8.7” (220 x 220 mm) Clean, Dry Air Supply: 11 CFM at 100 PSI (not to exceed 120 PSI) Dimensions: 88”L x 46W” x 35”H (2235 x 1170 x 890 mm) Weight: 2,046 lbs. (930 kg) Specifications are subject to change without notice. NOTE: Data is provided by the manufacturer. WARRANTY: 1 YEAR – Parts
