Sale!

DAKE Ratchet Leverage Arbor Press MODEL 1-1/2

$ 36.18

Category: Side Panels

Description 3 ton ratchet lever bench model arbor press that is designed with a friction brake and fixed table. Ratchet device permits lever to be used in most convenient position. Counterweight returns lever quickly after downstroke. Handwheel advanced ram to work quickly. STANDARD EQUIPMENT: Cast Iron Base Handwheel Ram Notched Table Plate Counter weight SPECIFICATIONS: Capacity: 3 Tons Leverage Ratio: 48:1 Ram Size: 1-1/4 x 1-1/4 x 16-1/2 in. Maximum Diameter Work: 14 in. Throat: 7 in. Largest Arbor: 2 in. Maximum ram to table: n/a Minimum ram to table: n/a Capacity Over Table: 11-1/2 in. Capacity Over Table Plate: 10-3/4 in. Base Length: 18 in. Base Width: 7-1/4 in. Height: 19 in. Weight: 145 lbs. Specifications are subject to change without notice. NOTE: Data is provided by the manufacturer. WARRANTY: 1 YEAR – Parts OPTIONAL ITEMS: Pedestal Only for No. 1-1/2 Press: $575.00
