Description ISO 9001 certified 3HP Heavy Duty AC main motor, 220V, 3 phase Heavy welded all steel construction for maximum rigidity It’s a Triplex, standard rolls include S & Drive (Slip & Drive Cleat), Drive Cleat, Double Seam, Pittsburgh Lock, Power Flanger, 5 in 1, all rolls are installed. ACME side can be operated at same time One year warranty for parts STANDARD EQUIPMENT: Standard Pittsburgh Attachment # PA-18E, installed Slip & Drive Roll (S & Drive)# SDR-18E , installed Drive Cleat Roll # DCR-18E, installed Double Seam Roll # DSR-18E, installed Power Flanger # PF-18E, installed SPECIFICATIONS: Capacity Pittsburgh Lock: 26 Ga. – 18 Ga. S Drive Lock: 26 Ga. – 20 Ga. Right Angle Lock: 26 Ga. – 20 Ga. Drive Cleat Lock: 26 Ga. – 18 Ga. Double Seam Lock: 26 Ga. – 18 Ga. Power Flange 1/4: 26 Ga. – 20 Ga. Depth of Pocket: 1/2 in. Feeding Speed: 23 FPM Main Motor: 3 HP, 3 Phase, 10 AMP Prewired: 220VAC: 220V, 1phase is optional Weight Approx: 908 lbs. Machine Dimensions (LxWxH): 60 x 26 x 46 in. Shipping Dimensions: 63 x 27 x 48 in. OPTIONAL ITEMS: RAR-18E: Right Angle Roll set: 1/4”, 3/8” & 1/2” – $CALL Digital Inverter Drive control box for converting to PL-18E-1phase – $CALL Specifications are subject to change without notice. NOTE: Data is provided by the manufacturer. WARRANTY: 1 YEAR – Parts
