CPU Support:Compatible with Intel® Core™ Ultra (Series 2) CPUs.Supports Intel Turbo Boost 2.0 & Max Technology 3.0 depending on CPU. Chipset:Intel® B860 Chipset – optimized for the newest generation of CPUs and I/O. Memory: 4 x DIMM slots, up to 256GB DDR5 Supports up to 8600 MT/s (OC) Dual channel, Intel XMP and ASUS AEMP III profiles. Graphics Output (CPU-dependent): 1 x HDMI 2.1 (4K@60Hz) 1 x DisplayPort 1.4 (8K@30Hz) 1 x USB4® Type-C (DP Alt Mode up to 4K@60Hz) Expansion Slots: 1 x PCIe 5.0 x16 (from CPU) 1 x PCIe 4.0 x16 (x4 mode) (from chipset) Storage: 4 x M.2 slots 1 x PCIe 5.0 x4 (CPU) 3 x PCIe 4.0 x4 (Chipset) 4 x SATA 6Gb/s RAID 0/1/5/10 supported. Networking: Intel® 2.5Gb Ethernet Wi-Fi 7 (802.11be) with Bluetooth 5.4 Up to 2.9Gbps, supports 2.4/5/6GHz bands Full Wi-Fi 7 functionality requires Windows 11 24H2 or newer USB Ports: Rear I/O (10 ports): 1 x USB4® (Type-C, 20Gbps) 3 x USB 10Gbps (2 Type-A 1 Type-C) 2 x USB 5Gbps (Type-A) 4 x USB 2.0 Front panel support: 1 x USB-C 10Gbps, 2 x USB 5Gbps, 2 x USB 2.0 (via headers) Audio: Realtek ALC1220P 7.1 Surround Sound Features include S/PDIF out, high-end AMP, audio shielding, and premium capacitors Cooling & Power: 6 x 4-pin fan headers (CPU, AIO, chassis) 2 x 8-pin CPU power connectors VRM & M.2 heatsinks included Form Factor: ATX (12″ x 9.6″) Software & Features: ASUS Armoury Crate, Fan Xpert 4, AI Overclocking BIOS FlashBack™, Clear CMOS, and Q-Design for easy DIY Aura Sync RGB with Gen2 headers Bundled Accessories:Includes Wi-Fi antenna, SATA cables, M.2 accessories, and more
