CPU Support Socket Type: LGA1851 Compatible Processors: Intel® Core™ Ultra Series 2 Supported Technologies: Intel® Turbo Boost Technology 2.0 Intel® Turbo Boost Max Technology 3.0* *Support depends on specific CPU models For full CPU support list, visit: ASUS CPU Support Chipset Chipset: Intel® B860 Memory Memory Slots: 4 x DDR5 DIMM slots Maximum Memory Capacity: 256GB Supported Speeds: Up to 8666 MT/s (OC) Architecture: Dual Channel Memory Types: Non-ECC, Un-buffered DIMMs (CUDIMM) Intel® Extreme Memory Profile (XMP) Support ASUS Enhanced Memory Profile III (AEMP III) On-Die ECC Support: Yes (DDR5 standard feature) Memory performance may vary by CPU and module configuration Graphics Integrated Graphics Support: Yes (depends on CPU) Video Outputs: 1 x HDMI™ 2.1 (4K @ 60Hz) 1 x DisplayPort 1.4 (4K @ 60Hz) VGA output resolution support depends on processor capability Expansion Slots From CPU: 1 x PCIe 5.0 x16 slot From Chipset: 1 x PCIe 4.0 x16 slot (x4 mode) 3 x PCIe 4.0 x16 slots (x1 mode) Check peripheral compatibility at ASUS Support Storage Interfaces M.2 Slots: M.2_1 (CPU): PCIe 5.0 x4, 2242/2260/2280 M.2_2 (Chipset): PCIe 4.0 x4, 2242/2260/2280/22110 SATA Ports: 4 x SATA 6Gb/s ports RAID Support: SATA RAID 0, 1, 5, 10 (Intel® Rapid Storage Technology) Networking Wired LAN: Realtek 2.5Gb Ethernet ASUS LANGuard Protection Wireless Connectivity: Wi-Fi 6E (802.11ax, 2×2) – 2.4/5/6 GHz Bluetooth® v5.3 *6GHz Wi-Fi and Bluetooth version may vary by region and OS. Wi-Fi 6E requires Windows 11 or later. Rear I/O Ports 1 x USB 3.2 Gen 2×2 Type-C® (20Gbps) 2 x USB 3.2 Gen 2 Type-A (10Gbps) 1 x USB 3.2 Gen 1 Type-A (5Gbps) 4 x USB 2.0 Type-A 1 x DisplayPort 1 x HDMI™ port 1 x Wi-Fi module connector 1 x Realtek 2.5Gb Ethernet port 3 x Audio jacks (Line-out, Line-in, Mic) Internal I/O Headers Power: 1 x 24-pin ATX Main Power 1 x 8-pin 12V CPU Power Cooling: 1 x 4-pin CPU Fan 1 x 4-pin CPU OPT Fan 1 x 4-pin AIO Pump 4 x 4-pin Chassis Fans USB Headers: 1 x USB 3.2 Gen 1 Type-C 1 x USB 3.2 Gen 1 Header (2 x ports) 1 x USB 2.0 Header (2 x ports) Storage Headers: 2 x M.2 Slots (Key M) 4 x SATA 6Gb/s ports Other Headers: 3 x Addressable Gen 2 RGB 1 x Aura RGB Header 1 x COM Port Header 1 x Clear CMOS Header 1 x Chassis Intrusion 1 x Front Panel Audio 1 x S/PDIF Out 1 x Thunderbolt™ (USB4®) Header 1 x SPI TPM (14-1 Pin) 1 x 10-1 pin System Panel Header Audio Codec: Realtek 7.1 HD Audio Output: Supports up to 24-bit/192kHz Features: Jack-detection and front panel retasking Audio shielding Premium capacitors Dedicated PCB layers Front-panel 7.1 audio output requires compatible HD chassis module Software Package ASUS Utilities: Armoury Crate Aura Creator & Aura Sync Fan Xpert 2 Power Saving ASUS AI Advisor ASUS DriverHub ASUS GlideX ASUS CPU-Z Included Software Trials: Adobe Creative Cloud (Free Trial) Norton 360 Deluxe (60 Days) WinRAR (40 Days) BIOS BIOS ROM: 2 x 128 Mb Flash Type: UEFI AMI BIOS Features: ASUS EZ Flash CrashFree BIOS 3 EZ Mode Interface ASUS MyHotkey Special Features ASUS 5X Protection III: DIGI VRM LANGuard Overvoltage Protection SafeSlot Stainless Steel Back I/O Q-Design: Q-Antenna Q-LED Diagnostic Indicators Q-DIMM Latches Q-Slot for GPUs Thermal Management: M.2 Heatsink VRM Heatsink DIY Friendly: ProCool Power Connectors Pre-mounted I/O Shield Aura Sync Support: 1 x Aura RGB Header 3 x Addressable Gen 2 RGB Headers Accessories Included 2 x SATA 6Gb/s Cables 1 x ASUS WiFi Q-Antenna 1 x M.2 Rubber Package 1 x M.2 Screw Package 1 x Quick Start Guide
