CPU Support Compatible with Intel® Core™ Ultra Processors (Series 2) on LGA1851 socket Supports Intel® Turbo Boost Technology 2.0 and Turbo Boost Max Technology 3.0 Chipset Intel® B860 Chipset Memory 4 x DDR5 DIMM slots, up to 256GB Supports up to 8666 MT/s (OC), Non-ECC, Unbuffered, and CUDIMM modules Dual-channel architecture Intel® XMP and ASUS AEMP III support Graphics Outputs 1 x HDMI 2.1 port (4K@60Hz) 1 x DisplayPort 1.4 (4K@60Hz)(Output depends on CPU capabilities) Expansion Slots 1 x PCIe 5.0 x16 (CPU) 1 x PCIe 4.0 x16 (x4 mode) 3 x PCIe 4.0 x1 slots Storage Options 2 x M.2 slots M.2_1: PCIe 5.0 x4 (CPU) M.2_2: PCIe 4.0 x4 (Chipset, up to 22110) 4 x SATA 6Gb/s ports Supports Intel® RAID 0/1/5/10 Networking Realtek 2.5Gb Ethernet with ASUS LANGuard Wi-Fi 6E (802.11ax, 2×2, supports 2.4/5/6 GHz) Bluetooth® 5.3 USB Connectivity Rear Ports (8 total): 1 x USB 3.2 Gen 2×2 Type-C® (20Gbps) 2 x USB 3.2 Gen 2 Type-A (10Gbps) 1 x USB 3.2 Gen 1 Type-A (5Gbps) 4 x USB 2.0 Type-A Front Panel (5 ports via headers): 1 x USB 3.2 Gen 1 Type-C® 1 x USB 3.2 Gen 1 header (2 ports) 1 x USB 2.0 header (2 ports) Audio Realtek 7.1 Surround Sound High Definition Audio CODEC Premium capacitors, audio shielding, and dedicated PCB layers Supports up to 24-bit / 192 kHz playback Cooling & Power Headers 1 x CPU fan 1 x CPU optional fan 1 x AIO pump 4 x Chassis fan headers 24-pin ATX main power 8-pin CPU power RGB & Customization 3 x Addressable Gen 2 RGB headers 1 x Aura RGB header Supports Aura Sync Internal I/O & Miscellaneous TPM header, COM header, SPDIF, front panel audio Clear CMOS, chassis intrusion, Thunderbolt™ (USB4®) header Special Features ASUS 5X Protection III (SafeSlot, LANGuard, Overvoltage, DIGI VRM) Q-Design (Q-DIMM, Q-LED, Q-Slot, Q-Antenna, Q-Dashboard) EZ DIY features: ProCool, Pre-mounted I/O shield Thermal: VRM & M.2 heatsinks Software Armoury Crate (Aura Sync, Fan Xpert 2 , AI Advisor) ASUS CPU-Z, Norton 360 (60-day trial), WinRAR Creative Cloud free trial BIOS Dual 128Mb UEFI AMI BIOS EZ Mode, CrashFree BIOS 3, EZ Flash, MyHotkey OS Compatibility Windows® 11 (22H2 ), Windows® 10 64-bit (21H2 ) Form Factor ATX (30.5 cm x 24.4 cm) In the Box 2 x SATA 6Gb/s cables 1 x ASUS WiFi Q-Antenna M.2 rubber & screw kits Quick Start Guide
