Description Description XT1 Series 107cm / 42 The Cub Cadet XT1 OS107 garden tractor has a 107cm / 42” cutting width delivering a perfect cut, done in the quickest time. Easy to use and quick to adjust, setting the height from one of the 12 deck height settings is done with the simple movement of a lever and with a wide height range of 25mm – 100mm to choose from, the enjoyment can begin. The XT1 OS107 also features built-in soft touch cruise control, making mowing large areas an easy and relaxing activity. ENGINE XT1 OS107 Engine Cub Cadet Engine displacement (cm3) 547 Rated power (kW/min-1) 6.6 / 2,250 Cylinders Single Fuel tank capacity(l) 11.4 DRIVE SYSTEM Transmission Hydrostatic Air speed (max) Stepless (f/r) Control Foot pedal control Cruise Control Standard CUTTING SYSTEM Mowing area (m2/h) 8,000 Cutting width 107cm / (42”) Cutting height 25-100 mm Number of blades 2 Deck Engagement Electric PTO Deck height positions 12 positions Deck wheels 2 balls deck wheels Wash nozzle / mulching plug Standard/Standard DISCHARGE SYSTEM Grass bag capacity (l) / accessory no. Optional 200/Optional (19A30030100) Bag lever / hardtop – / – Bag full indicator / Grass Deflector – / Standard FRAME Front axle Heavy-duty cast-iron Front bumper Standard Turning radius (cm) TIGHT TURN 38cm Wheels (front/rear) (Zoll) 15 x 6 / 20 x 8 Wheel bearings Sleeve bearings Frame Robotically-welded ELECTRIC Headlights LED COMFORT Seat type Cut & Sew, high back rest Seat adjustment Lever, angled,10 slide Steering wheel Ergonomic with gentle touch Tool box / Cub holder Standard / Standard 12V Plug Mow in reverse Standard Battery charger – DIMENSIONS Noise values (dB) 88 / 98 / 100 Vibration value body (K-factor) (m/s2) 1.0 / 0.5 Vibration value hand-arm (K-factor) (m/s2) 5.0 / 1.5 Dimensions (L / W / H) (cm) 175 / 134 / 110 Weight net (kg) 195
