Description Description XT1 Series 96cm/38 The Cub Cadet XT1 OS96 features a 38” cutting deck with a side discharge and an adjustable cutting height range, from 25mm – 100mm. The powerful and reliable single cylinder Cub Cadet 547cm³ engine is joined to a smooth hydrostatic transmission for simple and efficient mowing. The cutting blades are activated with the pull of a button and the deck height can be easily adjusted through 12 height positions and engaged with the electric PTO system. ENGINE XT1 OS96 Engine Cub Cadet Engine displacement (cm3) 547 Rated power (kW/min-1) 9.0 / 2,300 Cylinders Single Fuel tank capacity(l) 11.4 DRIVE SYSTEM Transmission Hydrostatic Air speed (max) Stepless (f/r) Control Foot pedal control Cruise Control Standard CUTTING SYSTEM Mowing area (m2/h) 6,000 Cutting width 96cm (38”) Cutting height 25-100 mm Number of blades 2 Deck Engagement Electric PTO Deck height positions 12 positions Deck wheels 2 balls deck wheels Wash nozzle / mulching plug – /Standard DISCHARGE SYSTEM Grass bag capacity (l) / accessory no. Optional 200/Optional (OEMR190-180A) Bag lever / hardtop – / – Bag full indicator / Grass Deflector – / Standard FRAME Front axle Heavy-duty cast-iron Front bumper Standard Turning radius (cm) TIGHT TURN 38cm Wheels (front/rear) (Zoll) 15 x 6 / 20 x 8 Wheel bearings Sleeve bearings Frame Robotically -welded ELECTRIC Headlights LED COMFORT Seat type Cut & Sew, high back rest Seat adjustment Lever, angled,10 slide Steering wheel Ergonomic with gentle touch Tool box / Cub holder Standard / Standard 12V Plug Mow in reverse Standard Battery charger – DIMENSIONS Noise values (dB) 88 / 98 / 100 Vibration value body (K-factor) (m/s2) 1.0 / 0.5 Vibration value hand-arm (K-factor) (m/s2) 5.0 / 1.5 Dimensions (L / W / H) (cm) 175 / 131 / 110 Weight net (kg) 195
