Description Description ULTRA-RELIABLEV-BELT DESIGN Thanks to reduced fan belt tension and ingenious, perfect fan beltguidance without twisted fan belts, the Cub Cadet mowing deck operateswith impressive stability and endurance.The XT2 PS117i and XT3 QS137 tractors are also equipped with a weldedmowing deck, which is even sturdier and more durable (see photo on the right). ENGINE XT3 QR106 Engine Kawasaki Engine displacement (cm3) 726 Rated power (kW/min-1) 11,8 / 2.200 Cylinders V-TWIN dual cylinder Fuel tank capacity(l) 11,4 DRIVE SYSTEM Transmission Hydrostatic, with differential lock Air speed (max) stepless (f/r) Control Foot pedal control Cruise Control Standard CUTTING SYSTEM Mowing area (m2/h) 8.000 Cutting width 106 Cutting height 25–100 Number of blades 2 Deck Engagement Electric PTO Deck height positions 12 positions Deck wheels 4 balls deck wheels Wash nozzle / mulching plug Standard /optional (196-550-000) DISCHARGE SYSTEM Grass bag capacity (l) / accessory no. 360 l, with Anti dust system/– Bag lever / hardtop Rounded ergo telescopic handle / Plastic Bag full indicator / Grass Deflector with blade switch-off / optional (196-552A000) FRAME Front axle Heavy-duty cast-iron Front bumper Bull Bar Turning radius (cm) TIGHT TURN xTREME 17 Wheels (front/rear) (Zoll) 15 x 6 / 18 x 8,5 Wheel bearings Sleeve bearings Frame robotically-welded ELECTRIC Headlights LED COMFORT Seat type Cut & Sew, high back rest, with arm rests Seat adjustment Lever, angled, 10 slide Steering wheel Ergonomic with gentle touch Tool box / Cub holder Standard / Standard 12V Plug Mow in reverse Standard Battery charger – DIMENSIONS Noise values (dB) 83,7 / 98,9 / 100 Vibration value body (K-factor) (m/s2) 0,2 / 0,5 Vibration value hand-arm (K-factor) (m/s2) 2,0 / 1,0 Dimensions (L / W / H) (cm) 267 / 110 / 118 Weight net (kg) 268
