Description Description XT1 Series 95cm/38 The solid, stable and durable frame features an e-coating corrosion defence system providing the ultimate stability and protection. The cutting blades are activated with the simple pull of a button and the height of the cut can be adjusted through a wide range of 25mm to 100mm. The hydrostatic drive system ensures a smooth ride and is very simple to operate, just push the pedal and go. The XT1 OR95 features a unique anti-clog system, designed to transport the grass clippings into the grass bag in the most efficient and effective way. Optional rear grass deflector is also available for use when collection is not required. ENGINE XT1 OR95 Engine Cub Cadet Engine displacement (cm3) 547 Rated power (kW/min-1) 6.2 / 2,100 Cylinders Single Fuel tank capacity(l) 11.4 DRIVE SYSTEM Transmission Hydrostatic Air speed (max) Infinitely variable (f/r) Control Foot pedal control Cruise Control Standard CUTTING SYSTEM Mowing area (m2/h) 5,500 Cutting width 95cm (38”) Cutting height 25-100 mm Number of blades 2 Deck Engagement Electric PTO Deck height positions 12 positions Deck wheels 2 balls deck wheels Wash nozzle / mulching plug Standard/Optional (196-551-000) DISCHARGE SYSTEM Grass bag capacity (l) / accessory no. 320/(196-555-603 Anti-Dust-System) Bag lever / hardtop Rounded ergo telescopic handle / Plastic Bag full indicator / Grass Deflector With Blade Shutoff / (196-552-A000) FRAME Front axle Heavy-duty cast-iron Front bumper Standard Turning radius (cm) TIGHT TURN 38cm Wheels (front/rear) (Zoll) 15 x 6 / 18 x 8.5 Wheel bearings Sleeve bearings Frame Robotically-welded ELECTRIC Headlights LED COMFORT Seat type Cut & Sew, high back rest Seat adjustment Lever, angled, 10 slide Steering wheel Ergonomic with gentle touch Tool box / Cub holder Standard / Standard 12V Plug Mow in reverse Standard Battery charger – DIMENSIONS Noise values (dB) / / 100 Vibration value body (K-factor) (m/s2) 1.0 / 0.5 Vibration value hand-arm (K-factor) (m/s2) 5.0 / 1.5 Dimensions (L / W / H) (cm) 245 / 100 / 118 Weight net (kg) 215
